VS121 & VS121-P AI Workplace Occupancy Sensors – Smart People Counting with Privacy-First Intelligence The Milesight VS121 and VS121-P are advanced AI-powered workplace sensors designed for accurate people counting, occupancy...

Stock Adequate！Ready to ship

Model: VS121-915M PN: White / Black | Installation Height 2.5-5m
AI Workplace Occupancy Sensor VS121
Dhs. 2,312.10 AED
VS121-915M PN: Wh...

Payment and security

  • American Express
  • Apple Pay
  • Mastercard
  • Visa
View details

VS121 & VS121-P AI Workplace Occupancy Sensors – Smart People Counting with Privacy-First Intelligence

The Milesight VS121 and VS121-P are advanced AI-powered workplace sensors designed for accurate people counting, occupancy tracking, and space utilization analysis. Built with an intelligent algorithm achieving up to 98% recognition accuracy, these sensors offer real-time insights across modern offices, retail environments, airports, and public facilities. The VS121 supports lorawan® connectivity, while the VS121-P offers PoE-powered Ethernet transmission and additional industrial interfaces for flexible deployments.

Key Features

  • AI-powered detection with up to 98% recognition rate
  • Supports region mapping, dwell time detection, and bidirectional line-crossing counting
  • Smart U-turn filtering and multi-direction people flow analysis
  • No image storage – GDPR compliant, privacy-focused design
  • Supports up to 16 mapped regions and 8 privacy masks
  • Local data storage and retransmission supported
  • Compact ceiling-mounted form factor with wide field-of-view

lorawan® Version (VS121) Features

  • lorawan® and Milesight D2D protocol supported
  • Up to 3000 retransmission packets stored locally
  • Wi-Fi-based GUI for configuration
  • Easy cloud integration via Milesight IoT Cloud

PoE Version (VS121-P) Features

  • Supports HTTP/MQTT push and API integration via Ethernet
  • Remote management via Milesight DeviceHub or Development Platform
  • Industrial interfaces: DI/DO and RS485 (future support)
  • DC or 802.3af PoE power options

Technical Specifications

Model VS121 (lorawan®) VS121-P (PoE)
Field of View Standard: 190°H / 112°V | High Ceiling: 129.4°H / 68.4°V
Installation Height 2.5–4m 5–7m
People Counting Accuracy Up to 98% (Flow Analysis)
Detection Features 16 regional zones, dwell time, U-turn filtering, bi-directional counting
Connectivity lorawan®, Wi-Fi Ethernet (HTTP/MQTT), DI/DO, RS485
Data Storage 3000 packets 3 × 1000 packets
Power Supply 5V/1.5A (USB-C) 5V/2A (DC) or 802.3af PoE
Power Consumption 3.5W 3.5W (DC), 4.5W (PoE)
Ingress Protection IP30
Dimensions 85 × 85 × 20 mm 85 × 85 × 30 mm
Operating Temp -5°C to +55°C
Certifications CE, FCC, GDPR, RoHS

Recommended Mounting Heights & Detection Ranges

Height (m) Detection Area (m²)
2.5 3.2 × 9.8
3.0 4.8 × 14.0
4.0 6.8 × 18.8
6.0 (High Ceiling) 4.5 × 12.0
7.0 (High Ceiling) 5.5 × 14.0

Ideal Applications

  • Smart Office and Meeting Room Utilization
  • Retail Analytics and People Flow Optimization
  • Airport and Transportation Hub Occupancy
  • Public Infrastructure and Campus Footfall Analysis

Privacy-Safe Intelligence. Real-Time Space Insights.

With best-in-class AI detection, zero image storage, and versatile connectivity, the VS121 series delivers actionable occupancy data while ensuring full privacy compliance. Ideal for smart building transformations across the MEA region, supported by TerraQ Technologies.
