Outdoor kiosk

Dhs. 0.00 AED
Shipping calculated at checkout.
Outdoor Kiosk – Built for All‑Weather Engagement TerraQ’s Outdoor Kiosk delivers sunlight‑readable visuals, rugged construction, and cloud‑first control for drive‑thru lanes, forecourts, campuses, and public spaces. Designed for 24/7 reliability...
Outdoor kiosk
Dhs. 0.00 AED

Payment and security

View details

Outdoor Kiosk – Built for All‑Weather Engagement

TerraQ’s Outdoor Kiosk delivers sunlight‑readable visuals, rugged construction, and cloud‑first control for drive‑thru lanes, forecourts, campuses, and public spaces. Designed for 24/7 reliability with vandal‑resistant materials and high‑brightness panels.

Why TerraQ Outdoor Kiosk?

  • Sunlight Readable: High‑brightness panel (up to ~2000 nits) for clear visibility in daylight.
  • Ruggedized Enclosure: Metal chassis with tempered glass and weather protection (IP‑rated).
  • Smart OS Inside: Android‑based player for smooth media playback and remote device management.
  • Two‑Way Readiness: Optional mic/speaker kit for clear, hands‑free communication (drive‑thru).
  • Cloud Control: Manage content, schedules, and health status via TerraQ’s Cloud Adword CMS.
  • Long Duty Cycle: Commercial components engineered for continuous 24/7 operation (~50,000 hrs).

Representative Specifications (Drive‑Thru Model)

Model PDDTK55DS
Screen Size 55″ LCD
Resolution 1920 × 1080 (FHD)
Brightness ≈ 2000 nits (daylight‑viewable)
Contrast Ratio ≈ 1200:1
Enclosure Metal body, 6 mm tempered protective glass, weather‑resistant
Ingress Protection IP55 (typical for outdoor kiosks)
CPU / OS RK3288 • Android 11
Memory 4 GB RAM / 32 GB storage
Connectivity Wi‑Fi / LAN
Ports USB 2.0 ×4, RJ45 ×1
Comms (Optional) Two‑way mic & speaker kit; vehicle detector input
Unit Dimensions ~ 1940 × 1492 × 250 mm
Working Life ≈ 50,000 hours

Specifications vary by configuration and region. Contact TerraQ for the latest datasheet and compliance certificates.

Applications

  • QSR Drive‑Thru: Dynamic menus, upsell promos, two‑way audio for ordering.
  • Retail & Fuel: Forecourt offers, loyalty prompts, safety messages.
  • Education & Healthcare: Wayfinding, check‑in, parking guidance.
  • Municipal & Transit: Public notices, ticketing info, service updates.
  • Events & Venues: Schedules, sponsor loops, and last‑minute changes.

Design, Schedule, Monitor – From the Cloud

  • Cloud Adword CMS: Create playlists, day‑part menus, and region‑specific campaigns.
  • Fleet Health: Online status, last content push, and uptime alerts across sites.
  • Offline Resilience: Pre‑cached media ensures continuous playback during network drops.

Deployment & Integration

  • Install Options: Floor‑standing pedestal with secure base; service access for maintenance.
  • Power & Thermal: AC 100–240 V, 50/60 Hz; thermal management for hot climates.
  • Integration: Optional triggers (vehicle detector), external sensors, and signage players.
  • Content Types: Video, images, HTML5 layouts, and live data widgets.

Ready for the Outdoors. Ready for Your Brand.

Deploy TerraQ Outdoor Kiosks to deliver bright, reliable, and interactive experiences—managed centrally in the cloud.
Color pattern Black
Connectivity technology USB, Wi-Fi, Ethernet
Display resolution 1920 x 1080
Display technology LCD
Portability Stationary
Suitable space Outdoors
